Vibo Galaxy Swing-Out Pantry Unit

The perfect pantry storage solution.

Vibo Galaxy Swing-Out Pantry

The Galaxy Swing-Out Pantry is the perfect pantry storage solution. The internal baskets automatically move to the front as the door is opened for easier access. Install two units side-by-side, as seen at Home Base, for the ultimate gourmet pantry. A modern storage solution to the common kitchen pantry.

• 20kg front frame load capacity
• 80kg total capacity
• Height: 1700mm
• Available in 2 widths: 450mm or 600mm cabinet width
• Soft closing feature via soft close hinge (not included, 165 degree hinge needed)
• High quality chrome wire with non-slip melamine bases

• Technical Info
• Dimensions
• Drawings

For 450mm or 600mm Cabinet Doors
Available to suit 1150 – 1700mm Height

---

Codes:

VBPSOG450 450mm
VBPSOG600 600mm

450mm Door	W mm	D mm	H mm	Weight kg
Inner Baskets	376	211	75	3.00
Door Baskets	361	152	75	2.00
Frame for 1150mm Height	350	485	1190	9.33
Frame for 1700mm Height	350	485	1740	11.50



600mm Door	W mm	D mm	H mm	Weight kg
Inner Baskets	526	211	75	4.00
Door Baskets	526	152	75	2.90
Frame for 1150mm Height	505	485	1190	11.00
Frame for 1700mm Height	505	485	1740	13.50
